Engineering the quantity is less, the commodity concrete batching plant is nor willing to do or they don’t economic construction, concrete construction project site mixed.Mixing concrete pump is with the rapid and flexible, mobile convenience, speed, labor saving features.
Features
Performance and Advantages of Diesel Mixing Concrete Pump:
1. Specially designed for hydraulic tipping loading hopper and non accumulator hydraulic system.
2. Only a diesel engine to provide the power to drive tipping loading hopper cylinder, mixing drum, concrete pump stroke cylinders, swing cylinders, concrete pump agitator.
3. There is the isolation chamber sealing structure in stroke cylinder ever if the inlet of the stroke cylinder seal damage, can’t enter the hydraulic oil tank.
4. The electromagnetic clutch + timer control water system, automatic watering timer automatic control water supply.
5. The high median tank layout, oil flow into the hydraulic pump itself, to avoid the lack of oil to demand oil pump, high reliability,
6. The median tank layout, the center of gravity in the middle of the two wheels.
7. The concrete mixer and concrete pump can be easily separated, can realize the independent use and combined use. There are two parts- work alone and combination. And it is convenient for the replacement of the concrete piston. The concrete mixer drum is not the barrier located above the concrete pump stroke cylinder part of the inspection, maintenance, it is easy to be maintenance by pull the pump unit out from concrete mixer.
8. Diesel engine is on the rotary platform, with three different optional position: dragging, working and shipping container position. Working position is away from the hopper, avoid diesel close to the pollution source- loading hopper, to increase reliability, while expanding loader working space.
The most suitable projects and engineering:
1. 10 layer below the group main building structure.
2. Building and underground garage floor.
3. Civil construction of inclined roof.
4. Small bridges
5. Tunnels
6. Water conservancy slope
7. Small river locks and boat lock
8. Electric power communication tower base
9. Small wharf
10. Mine construction
11. Concrete roadway maintenance field site scattered
Parameters
| Item |
Unit |
TD-HBT2008-TD-JZC350 |
TD-HBT1506-TD-JZC350 |
TD-HBT0804-TD-JZC350 |
| Pump Max Output |
m3/h |
15 |
15 |
|
| Theoretical Output |
m3/h |
23 |
23 |
|
| Max. Pressure on Concrete |
Mpa |
8 |
8 |
|
| Delivery Cylinder |
mm |
180*800 |
180*800 |
|
| Outlet Opening Diameter |
mm |
Φ150 |
Φ150 |
Φ150 |
| Diesel Model |
|
F4L912(DEUTZ) |
SL3105ABK |
CY1115(YAMMAR) |
| Diesel Power |
kw |
45 |
35 |
30 |
| Max. Diameter of Aggregates |
mm |
40 |
40 |
30 |
| Max. Delivery Horizontal Distance |
m |
200 |
200 |
100 |
| Max. Delivery Vertical Distance |
m |
40 |
40 |
30 |
| Capacity of Charge Hopper |
L |
560 |
560 |
200 |
| Capacity of Discharge Hopper |
L |
350 |
350 |
300 |
| Length* Width*Heignt |
mm |
5500*2300*2700 |
5500*2300*2700 |
4120*2100*2600 |
| Weight |
kg |
4500 |
4300 |
3000 |
Performance and Advantages of Diesel Mixing Concrete Pump:
1. Specially designed for hydraulic tipping loading hopper and non accumulator hydraulic system.
2. Only a diesel engine to provide the power to drive tipping loading hopper cylinder, mixing drum, concrete pump stroke cylinders, swing cylinders, concrete pump agitator.
3. There is the isolation chamber sealing structure in stroke cylinder ever if the inlet of the stroke cylinder seal damage, can’t enter the hydraulic oil tank.
4. The electromagnetic clutch + timer control water system, automatic watering timer automatic control water supply.
5. The high median tank layout, oil flow into the hydraulic pump itself, to avoid the lack of oil to demand oil pump, high reliability,
6. The median tank layout, the center of gravity in the middle of the two wheels.
7. The concrete mixer and concrete pump can be easily separated, can realize the independent use and combined use. There are two parts- work alone and combination. And it is convenient for the replacement of the concrete piston. The concrete mixer drum is not the barrier located above the concrete pump stroke cylinder part of the inspection, maintenance, it is easy to be maintenance by pull the pump unit out from concrete mixer.
8. Diesel engine is on the rotary platform, with three different optional position: dragging, working and shipping container position. Working position is away from the hopper, avoid diesel close to the pollution source- loading hopper, to increase reliability, while expanding loader working space.
